Qomolangma 51in x 98in 1325 Multifunctional CNC Router, with Vacuum System
  • Qomolangma 51in x 98in 1325 Multifunctional CNC Router, with Vacuum System
  • Qomolangma 51in x 98in 1325 Multifunctional CNC Router, with Vacuum System
  • Qomolangma 51in x 98in 1325 Multifunctional CNC Router, with Vacuum System
  • Qomolangma 51in x 98in 1325 Multifunctional CNC Router, with Vacuum System
  • Qomolangma 51in x 98in 1325 Multifunctional CNC Router, with Vacuum System
  • Qomolangma 51in x 98in 1325 Multifunctional CNC Router, with Vacuum System
  • Qomolangma 51in x 98in 1325 Multifunctional CNC Router, with Vacuum System
  • Qomolangma 51in x 98in 1325 Multifunctional CNC Router, with Vacuum System
  • Qomolangma 51in x 98in 1325 Multifunctional CNC Router, with Vacuum System

Ver imagen más grande y otras vistas (con zoom)

Qomolangma 51in x 98in 1325 Multifunctional CNC Router, with Vacuum System

   |   118 Transacciones

Codigo del articulo:CNCR-N1-1325V

  • Precio Unitario : $ 8,112 - 9,544/set   (Aviso de Descuento) (en existencia)

    Precio de Mayoreo :
    • Cantidad (sets) Descuento Amount/set
      1. 1 0% $9,544
      2. 2 - 5 8% $8,780
      3. 6 - 10 15% $8,112
    • ¿Necesitas más cantidades, por favor haga clic en Pedido al mayoreo
    • Por Favor Eliga el Tipo
    US Warehouse China Warehouse
  • Cantidad: set(s) Costo Total : $9,544

  • Peso de Envio: 5641.0lb (2564.1kg) freightFlete

  • Submit your order online to get membership points, a proforma invoice will be sent to you after you submit the order.
    Add to Cart inquire
Buyer Protection

Qomolangma 51in x 98in 1325 Multifunctional cnc router, with Vacuum System
Vacuum system includes: Vacuum table, vacuum pump, dust collector

Applications:
Strong and sturdy, for a durable reliable performance. Easy operation at a reasonable price. Multi-functions and wide range of application make it possible to process any wooden products, advertising sign plates, acrylic cutting, etc. non-metal material can be processed. soft metal cutting, for example: copper, aluminum, Aluminous model board, etc.

Product Highlights:
• Uses an advanced DSP numerical controlling system, more ergonomically designed for convenient operation with the handle, large screen displays, and simple maintenance.
• Optimization of mechanical and electrical design to ensure good performance.
• Furnished with high inverter-driven spindle motor cooled by water.
• Unique intelligent calculation fully develops the potential of the engine and leads to high processing speed, the synchronization of curves and straight lines, smoother curves. Traveling high speed can reach up to 10m (394")/min.
• Unique and dynamic renewal of the system enables the customer (according to different processing requirements) to change the controlling ability of the system, and effectively improves the processing efficiency (start operation with the instructions of the technician from factory or agent)
• 32M saving capacity can store more than 3 processing files simultaneously, and read one at random.
• Connected with the machine via USB interface to enable data transmission in a second.
• More compatible: Ucancam V10, Type3, Router 8, and Type3, etc.
• It is able to keep engraving even when the electricity is cut off or the tool is broken.

QOMOLANGMA BRAND STORY:

Product Features:

Features a heavy, all-steel tube frame that ensures durability. It also makes your CNC machine more rigid, which reduces vibration and improves routing quality. A three-axis motion control system gives you tight control over routing quality for precision and quality cutting your customers will love.

Totally independent from PC platform, You can use it not connect computer anymore, very convenient.
Directly read files from U Disk, Easily process G code or PLT file with supersize, Reliable data protection and recover function.

Nc studio handle control: A11 3 axis linkage carving

Water Cooling Spindle
Power: 3KW (4HP)
Connection type: Collet ER25
Rated voltage: 220V or 380V
Rated speed: 24000 rpm
Max speed: 24000rpm
Rotation: Right
Origin: China


Stepper Motor&Pulley drive for X,Y axis

Gear & Rack for X,Y axis

Linear Square Guide: 20MM linear square guide with double bearings, an ultra-heavy type that achieves a deep grooved raceway with its diameter more approximate to the ball diameter and has high rigidity, vibration and shock resistance, and damping characteristics, which are required for machine tools.
This machine is suitable for UCANCAM 2D&3D CADCAM software. The standard software is Ucancam V10. If you need Other, please contact the customer service.

Vacuum table: The vacuum table multi-zoned which allows the operator to easily switch from full sheet processing to smaller part, gaskets can also be routed to accommodate various material sizes and styles. Fixtures can also be used if needed as we put aluminum alloys beside the vacuum table.

Dust Collector

Applications:
ACM Signs Chtting

ACM Building Wall Signage Cutting

3D Acrylic Letter Signage Signboard

Aluminum Brass Letters Cutting
