US Stock, EFR F6 130W CO2 Sealed Laser Tube 1650mmL for Laser Engraver
  • US Stock, EFR F6 130W CO2 Sealed Laser Tube 1650mmL for Laser Engraver
  • US Stock, EFR F6 130W CO2 Sealed Laser Tube 1650mmL for Laser Engraver
  • US Stock, EFR F6 130W CO2 Sealed Laser Tube 1650mmL for Laser Engraver
  • US Stock, EFR F6 130W CO2 Sealed Laser Tube 1650mmL for Laser Engraver
  • US Stock, EFR F6 130W CO2 Sealed Laser Tube 1650mmL for Laser Engraver
  • US Stock, EFR F6 130W CO2 Sealed Laser Tube 1650mmL for Laser Engraver
  • US Stock, EFR F6 130W CO2 Sealed Laser Tube 1650mmL for Laser Engraver
  • US Stock, EFR F6 130W CO2 Sealed Laser Tube 1650mmL for Laser Engraver
  • US Stock, EFR F6 130W CO2 Sealed Laser Tube 1650mmL for Laser Engraver
  • US Stock, EFR F6 130W CO2 Sealed Laser Tube 1650mmL for Laser Engraver

Ver imagen más grande y otras vistas (con zoom)

US Stock, EFR F6 130W CO2 Sealed Laser Tube 1650mmL for Laser Engraver

Free Shipping for USA Customers, Arrival in 4-6 weeks.



Codigo del articulo:CS-LT-F6-130W-US

  • Precio Unitario : $ 754 - 887/pc   (Aviso de Descuento) (en existencia)

    Precio de Mayoreo :
    • Cantidad (pcs) Descuento Amount/pc
      1. 1 0% $887
      2. 2 - 10 5% $843
      3. 11 - 30 10% $798
      4. 31 - 60 15% $754
    • ¿Necesitas más cantidades, por favor haga clic en Pedido al mayoreo
    • Por Favor Eliga el Tipo
    US Warehouse China Warehouse Local Pick up
  • Cantidad: pc(s) Costo Total : $887

  • Peso de Envio: 188.6lb (85.73kg) freightFlete

  • Submit your order online to get membership points, a proforma invoice will be sent to you after you submit the order.
    Add to Cart

Buyer Protection


Customers in Other Countries Please Click Here to Order:
/products/16276/efr f6_130w_co2_sealed laser_tube_1650mml for_laser_engraving machine 6000hr uselife.html
Tips:
• We will send a new one freely if the tube is broken during transit.
• Once received the laser tube, please check again at the first time. We need the damaged record from the courier as the proof before we send the new one free.

　Model

Length

(mm)

Diameter

(mm)

Output Power

(W)

 Max Power (W)

Current

(mA)

 Catalyst Lifespan Warranty Period
F6 1650±20 Ø80±2 130 150 30 Yes 6000h 300days


Feature:
F6 CO2 Laser Tube is launched in October 2011 with 3 years development, its' working life is up to 6000hours, the single tube power is up to 150W. The laser output is stable. The discharge tube is catalyst coated, the working life is much increased. Compared to similar product, the tube body length is shorter, the laser beam mode is better, the cutting speed is higher.

• Stability: The discharge glass tube body is imported from Germany. The laser beam mode is up to TEM00. The power is table. It is competitive for industrial application.
• Power: The power is 30% higher than other laser tube with same length.
• Long Life: The catalyst coating on discharge tube with unique electrode processing makes the laser out put is more stable, avoid power weaken during long time working.

Product upgrade:
• Use USA IIVI lens and windows & Germany Schott glass tube as discharge tube, performance, reliability, consistency is higher than other similar product.
• High voltage side uses a ceramic water cooling jacket, reduce problems compared to glass cap which is made by hand.Ceramic heat dissipation better.
• The silicone pipe is once molded product, water flow more smoothly.
• Improved production processing, reduce gas leakage.
• New machining electrode makes discharge more stable.

Product details:

Application:

Warranty: 300 Days
• Within 90 days from exit work date, if the user operates same as our manual and the output power is less than 80% of the rated power, we will provide new one instead of the defected one. The replaced laser tube has same new laser tube warranty. The single transportation freight will be afforded by buyer. When the laser tube structure is damaged changed, we will not be responsible.
• From 90 days to 300 days, if the user operates same as our manual and the output power is less than 80% of the rated power, we will repair or provide new one instead of the defected one according to fact. The single transportation freight will be afforded by buyer. When the laser tube structure is damaged changed, we will not be responsible.

  • Todo
  • Guia
  • Descripcion del articulo
  • Envio
  • Pago
  • Otro
Pregunta
I would like to buy one of these tubes 130w what power supply would I need? also what controller would I need? what would be the price for tube, power supply and controller including shipping to USA zip 98282? thanks chuck
By chuck767 from Brunei Nov 20,2017
Respuesta

Hi Chuck,many thanks for your questions,recommend you this power supply:http://www.sign-in-china.com/products/21439/original_efr_es150_power_supply_with_pfc_function_for_f6_f8_f10_zs1650_zs1850_co2_sealed_laser_tube.html About controller,please send us your old controller brand,model and photos to overseas10@sign-in-china.com,then we will give you nmore advice.Good day.


Por Sign-in-china Nov 20,2017
