Codigo del articulo:LED-DYB-HJY-P10-2
Precio Unitario : $ 18.67 - 23.34/pc (Aviso de Descuento)
Peso de Envio:
1.4lb (0.625kg)
Flete
El vendedor asume toda la responsabilidad de este listado
Cantidad: Pais:
Envío y manipulación | Para | Servico | Entrega* |
US $75.00 | Estadpos Unidos | Entrega express: TNT/DHL/FEDEX/UPS | Estimado entre |
Tiempo de Manejo |
Enviará generalmente dentro de 3 días hábiles después de recibir el pago aprobado. |
![]() |
Tenemos 4 almacenes en el extranjero en todo el mundo que ahora incluye: Rusia, EE.UU., Brasil y México. y Estamos creando otro en Europa. Normalmente, enviaremos su pedido desde el almacén más cercano a usted. si las existencias cerca de usted están agotadas, le enviaremos su pedido a usted directamente de China. |
![]() |
|
Forma de pago |
![]() |
|
Historial De Transacciones
Transacciones: 1156
Product advantage:
1. Super bright LED and plastic quality
2. High contrast can achieve good results
3. Weight is easy to install and remove
4. Single point, single light maintenance, low cost
5. Constant current mode is used to drive LED, even light, low power consumption.
6. Beads glue dispersing agent (DP), surface spray. The point light source into surface light source, to ensure consistency of better visual effect, more plump, soft.
7. 100% new material support rubber shell (PPA), seal
LED parameter
Color | LED Package | Brightness | Wave | Voltage | Test condition |
R | 3IN1 SMD 3535 |
500 | 624-629nm | 1.8-2.4V | 25°C 20mA |
G | 1380 | 523-528nm | 3.0-3.6V | 25°C 20mA | |
B | 295 | 464-469nm | 3.0-3.6V | 25°C 20mA |
Screen parameters
Type | P10 |
Pixel pitch (mm) | 10 |
Pixel density (dots /m2) | 10000 |
Pixel structure | 1R1G1B |
LED Package | SMD3535 |
Module Size (mm) | 320*160 |
Module Resolution (dots) | 32*16 |
Number of modules per square meter (PCS) |
19.53 |
Minimum viewing distance(m) |
≥10 |
Brightness (cd/m2) | ≥7500 |
Angle of view (degree) | ≤120° |
Scanning mode | 1/4 Scan constant current drive |
Module interface | HUB75 |
Input voltage (DC) | 4.8-5.5V |
Maximum power (w/m2) | 750 |
Average power (w/m2) | 280 |
Module weight (g) | 423 |
Gray level | Recommended level 16384 |
Control mode | Computer control, video synchronization, real-time display |
Effective communication distance without relay |
Non shielded twisted pair transmission distance of 100 meters, the maximum transmission of up to 130 meters |
Frame changing frequency | ≥ 60 rames/ second |
Pixel out of control rate | <0.0001(LED Industry standard: less than 3/10000) |
Display color number | 64G color (4096 gray levels under the condition of the number of colors) |
Module brightness uniformity |
>95% |
Color temperature | RGB color brightness through the software of 100 adjustable color temperature can be regulated according to the needs |
Contrast ratio | Software 100 adjustable |
MTBF MTDLF | ≥10000Hours |
Service life | ≥50000Hours |
Protection performance | Over temperature / overload / drop / image compensation / various correction techniques / over current / over voltage / lightning protection |
Using ambient temperature | Outdoor, -40 to 50°C |
