Feature:
1. Using brand LED as light source, it has high brightness, uniform color and strong antistatic ability.
2. Using DC12V constant current design, a single LED Module can be cut, with 40 cascades in each series.
3. Innovative design of diffuse reflector lens with a real 170 degree luminous angle;
4. Waterproof IP67 design;
Applicable: Mainly used for 6-25cm light-emitting words and light boxes.
Installation Notes:
(1) The main line of the power supply should be 2 x 1.5 mm or more (the corresponding main line of the power supply should be selected according to the load current). If the module power supply needs to be lengthened, the wire with the specifications of 0.75 mm_/18
(2) Module single lamp can be cut. When the module is cut short, first cut the power cord between the two modules with bevel pliers in the middle, peel the outer skin about 10 mm, and twist the corresponding color (white red line is positive, white blue line is negative) wire into a single strand, then use special waterproof tape for insulation and waterproof treatment, and finally check. The conductivity and reliability of the power supply wiring head should be that the wire can not be pulled out from the wiring head by hand.
(3) When the module is installed, first tear off the release paper from the bottom of the module, paste it into the lamp box or the advertisement sign and fix it initially, then use two ST2.5x10mm self-tapping screw to lock and reinforce it, or use the way of punching glass glue on both sides of the module to fix it.
(4)Waterproof tape or waterproof plug should be used at the end of the module to avoid damage caused by short circuit.
(5) Module standard cascade 20PCS, using DC12V single-ended power supply; maximum cascade 40PCS, using both ends of power supply, do not over-connect, to avoid excessive line current and damage products;
(6) Modules should not be completely exposed for outdoor use. Do not touch or work with electricity.
Learn more about us from the following links:
19th Reklama Pholygraf Trade Fair 2012
ISA International Sign Expo 2012
Buyers say:
Jackson, Andy and David from UK
Adam Fernanders from South Africa
a) The Stepped Price
According to the different procurement quantities of customers, Sign-in-China.com formulates different price levels for commodity. Hence, your purchase price will be ultimately attributed to the procurement quantity.
The Stepped Prices shown on the product page is as following:
b) Trial Order Price / Sample Price
We offer free samples or some lower priced products(the product price plus shipping cost only)for our customers easily to experience our products and services from purchasing.
For details, please click:
http://www.sign-in-global.com/product/sampleproduct.html
c) Limited Time Offers
Every Tuesday Sign-in-China.com releases the latest products for Limited Time Offer, and after one week, the original price will be recovered. We sincerely expect your timely attention to the discount activities of Limited Time Offers on Sign-in-China.com.
For details, please click:
http://www.sign-in-global.com/product/discount.html
d) Flash Wholesale
Every Monday Sign-In-China.com and cooperation factory jointly campaigns the Flash Wholesale products for bulk purchase customers, and after a week, the original price will be receovered. We sincerely expect your timely attention to the preferential activities on Sign-In-China.com.
For details, please click:
http://www.sign-in-global.com/product/featuredproduct.html
e) You decide the prices for Bulk Orders
If the commodity quality you choose beyonds the quantity of fourth step price on Sign-in-China.com, or if you think the website stepped prices don’t meet your bulk purchase demand, you can use our "Make Offer" service on Sign-in-China.com to fill out your planned purchase quantity and target price then submit as a Bulk Order, for which we will review and endeavor to realize the deal with you.
If you need bulk order , please enter here to Make Offer:
a) PayPal online payment
https://www.paypal.com/webapps/mpp/buying-online
b) PayPal direct payment (our PayPal account: lyh@chinasigns.cn)
https://www.paypal.com/webapps/mpp/make-online-payments
c) Credit card payment (through PayPal gateway, some areas may be restricted)
https://www.paypal.com/us/webapps/helpcenter/article/?articleID=94038&topicID=11500008&m=TTQ
d) Bank transfer
https://www.paypal.com/us/webapps/helpcenter/article/?articleID=94040&topicID=11500008&m=TTQ
e) Telegraphic Transfer (T/T) payment
(1) Place an order
(2) Get the bank account information of Sign-in-China.com
(3) Make the payment at the bank, and get the Payment Receipt
(4) Send the Payment Receipt to service@sign-in-global.com
(5) Receive the Tracking Number of your order
(6) Wait for your order.
Bank transfer payment information:
Learn more about us from the following links:
19th Reklama Pholygraf Trade Fair 2012
ISA International Sign Expo 2012
Buyers say:
Jackson, Andy and David from UK
Adam Fernanders from South Africa
For details, please refer to the following:
a) Bank Transfer (T/T) payment
(1) Place an order
(2) Get the bank account information of Sign-in-China.com
(3) Make the payment at the bank, and get the Payment Receipt
(4) Send the Payment Receipt to service@sign-in-global.com
(5) Receive the Tracking Number of your order
(6) Wait for your order.
Bank transfer payment information:
b) PayPal online payment https://www.paypal.com/webapps/mpp/buying-online
c) PayPal direct payment (our PayPal account: lyh@chinasigns.cn) https://www.paypal.com/webapps/mpp/make-online-payments
d) Credit card payment (through PayPal gateway, some areas may be restricted) https://www.paypal.com/us/webapps/helpcenter/article/?articleID=94038&topicID=11500008&m=TTQ
e) Bank transfer (through PayPal gateway) https://www.paypal.com/us/webapps/helpcenter/article/?articleID=94040&topicID=11500008&m=TTQ
f) Western Union Payment
Receiver’s First name: Zifei Receiver’s Last name: Li Address: 4th Floor., Building No.8, Community No.12. Advanced Business Park, No.188 Western Road of the 4th Ring, Fengtai, Beijing.
a) Confirm if your credit card requires verification: https://www.paypal.com/us/webapps/helpcenter/article/?solutionId=10568&m=SRE
b) Confirm if you have exceeded the limitation of maximum amount https://www.paypal.com/us/webapps/helpcenter/article/?solutionId=11516&m=SRE
c) Confirm if you have any other restrictions https://www.paypal.com/us/webapps/helpcenter/article/?articleID=94053&m=SRE
If you failed to make payment via PayPal, please choose Bank Transfer(T/T) or Western Union Payment.We will ship your order by Express or by sea and usually the carriers are FedEx, TNT, UPS, DHL, or EMS. It shall be quite safe during shipping with substantial package. It shall be quite safe during shipping with substantial package. Additionally, we will purchase insurance as a gift for your package.
For details, please click the following links:
Changes & Returns: http://www.sign-in-global.com/info/ChangesandReturns.html
Warranty: http://www.sign-in-global.com/info/QualityWarranty.html
LED Type | 2835 |
Waterproof Method | Injection Molding |
Specification | |
Working voltage: | 12VDC |
Power: | 1.65W |
Luminous flux: | 190lm |
Luminous angle: | 170° |
Number of LED: | 3LEDs/pcs |
Color temperature: | 6000-6500K |
Effect of light: | 115lm/w |
Protection level: | IP67 |
Appearance size: | 66.3*15.8*11.3mm(2.61"x 0.62"x 0.44") |
Appearance color: | White |
Connecting wire material: | UL1007 20AWG |
Weight: | 9g |
Standard cascade: | 40PCS/String |
Fixed screw: | M3 self tapping screws |
Working temperature: | -20~55°C |
Storage temperature: | -25~70°C |
Warranty period: | 5 years |
Escriba un comentario para New LED Module Designed for Internal Illumination Of Signs 12VDC 1.65W 190lm 170 Degree IP67 66x16x11mm
