US Stock, 51" x 98" 1325 CNC Router Machine with CCD Camera, PVC / KT Cutting Experts
  • US Stock, 51" x 98" 1325 CNC Router Machine with CCD Camera, PVC / KT Cutting Experts

Ver imagen más grande y otras vistas (con zoom)

US Stock, 51" x 98" 1325 CNC Router Machine with CCD Camera, PVC / KT Cutting Experts

Free Shipping for USA Customers, Arrival in 4-6 Weeks.

   |   49 Transacciones

Codigo del articulo:CNCR-S2-1325CCD-US

  • Precio Unitario : $ 22,821/set   (Aviso de Descuento)

    • Por Favor Eliga el Tipo
    China Warehouse US Warehouse
  • Cantidad: set(s) Costo Total : $22,821

  • Peso de Envio: 5593.1lb (2542.32kg) freightFlete

  • Submit your order online to get membership points, a proforma invoice will be sent to you after you submit the order.
    Add to Cart
Buyer Protection


The Products in US Stock Only Free Shipping to USA.
Canada and Mexico Customers need to pay the extra delivery charges, Please contact our customer service in advance.
Customers in Other Countries Please Click Here to Order:
/products/27617/51 quot x 98 quot 1325 cnc_router machine with ccd camera pvc kt cutting experts.html

51" x 98" (1300mm x 2500mm) cnc router Machine with CCD camera, PVC / KT cutting master
This cnc contour cutting system machine is high precision and low noise, highly reliable and efficient.it is a regular CNC router and a CCD cutting system.
It is a good working mate for UV flatbed printing system, advertising making, garment field KT board, PVC board (within 6mm / 0.236inches), leather and other soft material cutting good helper.

Applications:
Sign & graphics, digital printing, packaging, automotive, aerospace, HVAC
Materials Available:
Solar panel, polycarbonate panel, cardboard, graphic board, vinyl, leather, carpet, carbon composite, cork, expandable PVC, foam, fabric, gator foam, corrugated plastic, paper, closed cell foam, HVAC dust liner, rubber-silicon, rubber mat.

QOMOLANGMA BRAND STORY:

Feature:
. Digital Tangential Cutting Bed.
. Innovative tangential cutting system that uses a camera to capture and position the material。
. Ideal for finishing prints, best combination of printing and cutting industries。
. Low cost and high performance, ideal for low budget customers。
. Full cast iron body, imported linear guides, rack & gear scientifically installed and adjusted by experienced engineers.
1. Industrial steel pipe frame, with stable moving, low noise and high precision.
2. Contour is output by program automatically, which saves much time and work for users.
3. Japanese Shimpo planetary reducer, imported linear rails, ensures the high precision.
4. High power AC servo motor, ensure high precision under high speed.
5. The machine body of the engraving machine and the vibrating knife are integrated and applicable for the first time in China. So as to meet the customers demand for maximum speed and precision.
6. Designed by professional team, advanced structure, simple and generous exterior.

Specification:

Model CNCR-N1-Z1325CCD-US
Table Size 1440mm x 2630mm (56.7in x 103.5in)
Working Size 1300mm x 2500mm x 200mm (51.2in x 98.4in x 78.74in)
Max. Material Height 200mm (78.74in)
Spindle Power Water Cooling 3.0kw / 4HP
Speed RPM 0-24000rpm
Mark Recognition CCD Camera
Driver Leadshine AC Servo
Control System LEYU control system
Tool Diameter Ø3.175, Ø4, Ø6, Ø12.7
Mechanical Structure Square Steel Pipe
Transmission Synchronous Belt Drive; Ball Screw for Z; Rack & Pinion for X, Y
Guide Ways Linear Guide Ways
Repositioning Accuracy <0.03mm / 300mm (11.8inches)
MAX. Engraving Speed 20m / min
Traverlling Speed 60m / min
Table Top PVC Vacuum Table + Blanket
File Transfer USB
File Format G Code / HPGL / DXP
Software Ucancam V10
Power Supply

CNC router machine: AC220V single phase, 50hz - 60Hz, 15A
Vacuum pump: AC220V 50hz - 60Hz three phase, 23A
External Form Size   2050mm x 3060mm x 1650mm (80.7in x 120in x 65in)
Packing Size 3150mm x 2200mm x 1850mm (122in x 82.7in x 67in)
Net/Gross Weight 1000KG (2200ibs) / 1300KG (2860ibs)
Optional Models N1-1313, N1-1318, N1-1325, And N1-1530
Linear Square Guide 20MM linear square guide with double bearings, an ultra-heavy type that achieves a deep grooved raceway with its diameter more approximate to the ball diameter and has high rigidity, vibration and shock resistance, and damping characteristics, which are required for machine tools.

 Details Pictures:

Linear Square Guide: 20MM linear square guide with double bearings, an ultra-heavy type that achieves a deep grooved raceway with its diameter more approximate to the ball diameter and has high rigidity, vibration and shock resistance, and damping characteristics, which are required for machine tools.
